Industrial Ethernet Switch - FL SWITCH 1005N - 1085039

Technical data

Supply voltage

Typical current consumption

19 mA

Max. current consumption

110 mA

General

Mounting type

DIN rail

Net weight

161.3 g

Housing material

Polycarbonate fiber reinforced

MTTF

167.2 Years (MIL-HDBK-217F standard, temperature 25°C, operating

cycle 100%)

1627 Years (SN 29500 standard, temperature 25°C, operating cycle 21%)

1526 Years (Telcordia standard, 25°C temperature, 21% operating cycle (5

days a week, 8 hours a day))

Connection data

Connection method

Push-in spring connection

Conductor cross section solid min.

0.2 mm²

Conductor cross section solid max.

2.5 mm²

Conductor cross section flexible min.

0.2 mm²

Conductor cross section flexible max.

2.5 mm²

Conductor cross section AWG min.

24

Conductor cross section AWG max.

12

Stripping length

10 mm

Standards and Regulations

Electromagnetic compatibility

Conformance with EMC Directive 2014/30/EU

Interference emission

EN 61000-6-2 EN 61000-4-8 (electromagnetic fields) Criterion A

Conducted noise emission

EN 61000-6-2 Class A

Immunity to surge

EN 61000-6-2 EN 61000-4-5 (surge) Criterion B

Immunity to burst

EN 61000-6-2 EN 61000-4-4 (EFT burst) Criterion A

Immunity to EF

EN 61000-6-2 EN 61000-4-3 (electromagnetic fields) Criterion A

Immunity to ESD

EN 61000-6-2 EN 61000-4-2 (ESD) Criterion B

Immunity to conducted interference

EN 61000-6-2 EN 61000-4-6 (line noise immunity) Criterion A

Type of test

Free fall in accordance with EN 61131-2

Noise emission

EN 61000-6-4:2007 + A1:2011

Noise immunity

EN 61000-6-2:2005

Vibration (storage/transport)

5g, 150 Hz, in acc. with IEC 60068-2-6

Vibration (operation)

in acc. with IEC 60068-2-6: 5g, 150 Hz

Shock (operation)

30g (EN 60068-2-27)

UL, USA / Canada

UL 61010-1, UL 61010-2-201, UL 62368-1

Class I, Div. 2, Groups A, B, C, D, T4
