THS1007
SLAS286A – AUGUST 2000– REVISED DECEMBER 2002
www.ti.com
21
INITIALIZATION OF THE THS1007
The initialization of the THS1007 should be done according to the configuration flow shown in Figure 32.
Start
Use Default
Values?
Yes
Write 0x401 to
THS1007
(Set Reset Bit in CR1)
No
Write 0x401 to
THS1007
(Set Reset Bit in CR1)
Clear RESET By
Writing 0x400 to
CR1
Write the User
Configuration to
CR0
Write the User
Configuration to
CR1 ( Must Exclude
RESET)
Continue
Clear RESET By
Writing 0x400 to
CR1
Figure 32. THS1007 Configuration Flow
