ADRF6720

Data Sheet

ABSOLUTE MAXIMUM RATINGS

Table 3.

Parameter

Rating

Supply Voltage

−0.3 V to +3.6 V

I+, I−, Q+, Q−

−0.5 V to +1.5 V

LOIN+, LOIN−

16 dBm differential

REFIN

−0.3 V to +3.6 V

ENBL

−0.3 V to +3.6 V

VTUNE

−0.3 V to +3.6 V

CS, SCLK, SDIO

−0.3 V to +3.6 V

Maximum Junction Temperature

150°C

Operating Temperature Range

−40°C to +85°C

Storage Temperature Range

−65°C to +150°C

Stresses at or above those listed under Absolute Maximum

Ratings may cause permanent damage to the product. This is a

stress rating only; functional operation of the product at these

or any other conditions above those indicated in the operational

section of this specification is not implied. Operation beyond

the maximum operating conditions for extended periods may

affect product reliability.

THERMAL RESISTANCE

θJA is thermal resistance, junction to ambient (°C/W), and θJC is

thermal resistance, junction to case (°C/W).

Table 4. Thermal Resistance

Package Type

θJA1

θJC1

Unit

40-Lead LFCSP

30.23

0.44

°C/W

See JEDEC standard JESD51-2 for information on optimizing thermal

impedance.

ESD CAUTION

Rev. 0 | Page 8 of 44
