MODEL: MLV

MLV SPECIFICATIONS

ES-1356 Rev.8 Page 3/3

http://www.m-system.co.jp/

EXTERNAL VIEW

Front Cover (open)

Excitation Adj.

Gain Adj.

Span Adj.

Zero Adj.

LCD Meter

EXTERNAL DIMENSIONS & TERMINAL ASSIGNMENTS unit: mm (inch)

5

6

7

8

2

1

11

10

50 (1.97)

107 (4.21)

136 (5.35)

[3.3 (.13)]

40 (1.57)

50 (1.97)

7.8 (.31)

CLAMP

(top & bottom)

DIN RAIL

35mm wide

MTG HOLE

25 (.98) deep

SCREW

• When mounting, no extra space is needed between units.

3

9

4

SCHEMATIC CIRCUITRY & CONNECTION DIAGRAM

+

–

Isolation

*

Base Socket

Synchronous

Demodulation

Output

Driver

OUTPUT

1

2

U(+)

V(–)

POWER

7

8

*Option /E

Excitation

Z

S

10

6

3

11

9

LVDT

GAIN

EXC.

5

4

Specifications are subject to change without notice.
