MODEL: MXAB

MXAB SPECIFICATIONS

ES-1747 Rev.10 Page 7/7

http://www.m-system.co.jp/

SYSTEM CONFIGURATION EXAMPLES

■ Holding and Manual Backup in Case of Computer Failure

• MXAB Independently

• MXAB – ST/STL Combination

■ Field Backup for a DDC Control Loop

• MXAB – ST/STL Combination

■ Operator Control Station

■ Field Backup for Computer Outputs

COMPUTER

Control Valve

COMPUTER

Control Valve

Analog

Backup Sta.

< MXAB >

Analog

Backup Sta.

< MXAB >

Soft-Terminal

< ST >

COMPUTER

Control Valve

Controller

Soft-Terminal

< STL >

Analog

Backup Sta.

< MXAB >

REMOTE I / O

Control Valve

Analog

Backup Sta.

< MXAB >

Control Valve

<MXAB>

Control Valve

COMPUTER

Flowmeter

SYSTEM BUS

<MXAB>

Control Valve

Analog

Backup Sta.

< MXAB >

Soft-Terminal

< STL >

Specifications are subject to change without notice.
