MODEL: M2XR2

M2XR2 SPECIFICATIONS

ES-5087 Rev.11 Page 2/4

http://www.m-system.co.jp/

RELATED PRODUCTS

• PC configurator software (model: JXCON)

Downloadable at M-System’s web site.

A dedicated cable is required to connect the module to the

PC. Please refer to the internet software download site or

the users manual for the PC configurator for applicable

cable types.

GENERAL SPECIFICATIONS

Construction: Plug-in

Connection: M3 screw terminals (torque 0.8 N·m)

Screw terminal: Chromated steel (standard) or stainless

steel

Housing material: Flame-resistant resin (black)

Isolation: Input to output to power

Overrange output: Approx. -15 to +115 %

(Negative current output is not provided.)

Manual zero adjustments: -5 to +5 %

(factory setting: 0 %)

Manual span adjustments: 95 to 105 %

(factory setting: 100 %)

Programming: Downloaded from PC; input type and range,

output range, zero and span, simulating output, etc.

Burnout: Upscale standard; downscale or no burnout

optional by programming

Linearization: Standard

Status indicator LED: Blinking patterns indicate different

operating status of the transmitter.

Configurator connection: 2.5 dia. miniature jack;

RS-232-C level

INPUT SPECIFICATIONS

Maximum leadwire resistance: 20 Ω per wire (3-wire)

Sensing current: ≤ 1.0 mA

Temperature range: See Table 1.

If not specified, the input range is shown below.

1: JPt 100 (JIS '89) 0 – 100°C

3: Pt 100 (JIS '89) 0 – 100°C

4: Pt 100 (JIS '97, IEC) 0 – 100°C

5: Pt 50 Ω (JIS '81) 0 – 200°C

6:Ni 508.4 Ω 0 – 100°C

7: Pt 1000 0 – 100°C

8: Ni 100 0 – 100°C

9 :Cu 10 @25°C 0 – 100°C

OUTPUT SPECIFICATIONS

■ DC Current

Operational range: 0 – 24 mA DC

Output range: 0 – 20 mA DC

Minimum span: 1 mA

Offset: Lower range can be any specific value within the

output range provided that the minimum span is

maintained.

Load resistance: Output drive 15 V max.

(e.g. 4 – 20 mA: 750 Ω [15 V ÷ 20 mA])

If not specified, the output range is 4 – 20 mA DC.

■ DC Voltage

Code V1 (narrow spans)

Operational range: -3 – +3 V DC

Output range: -2.5 – +2.5 V DC

Minimum span: 250 mV

Code V2 (wide spans)

Operational range: -11.5 – +11.5 V DC

Output range: -10 – +10 V DC

Minimum span: 1 V

Offset: Lower range can be any specific value within the

output range provided that the minimum span is

maintained.

Load resistance: Output drive 1 mA max.

(e.g. 1 – 5 V: 5000 Ω [5 V ÷ 1 mA])

If not specified, the output range is shown below.

V1: 0 – 1 V DC

V2: 1 – 5 V DC

INSTALLATION

Power Consumption

•AC:

Approx. 3 VA at 100 V

Approx. 4 VA at 200 V

Approx. 5 VA at 264 V

•DC: Approx. 2 W

Operating temperature: -30 to +60°C (-22 to +140°F)

Operating humidity: 30 to 90 %RH (non-condensing)

Mounting: Surface or DIN rail

Weight: 120 g (0.26 lb)

PERFORMANCE

Accuracy: Table 1 value or ±0.1 % of span, whichever is

greater. Add 0.2 % when the output span equals 1/10 or

narrower of the max. span.

Temp. coefficient: ±0.015 %/°C (±0.008 %/°F) of max. span

at -5 to +55°C [23 to 131°F]

Response time: ≤ 0.9 sec. (0 – 90 %)

Burnout response: ≤ 10 sec.

Line voltage effect: ±0.1 % over voltage range

Insulation resistance: ≥ 100 MΩ with 500 V DC

Dielectric strength: 2000 V AC @1 minute (input to output

to power to ground)
