MODEL: 10JV

http://www.m-system.co.jp/

10JV SPECIFICATIONS

ES-0862 Rev.9 Page 2/3

range, zero and span, simulating output, etc.

(Input range can be changed with Codes U1, U2 or U3 and

limited within ranges of each code type.)

(Refer to the users manual of JXCON for the adjustments

configurable with JXCON.)

INPUT SPECIFICATIONS

■ DC Current: Input resistor incorporated

■ DC Voltage: -10 – +10 V DC

Minimum span: 3 mV

Offset: Max. 3 times span

Default setting will be used if not otherwise specified.

U1: 0 – 100 mV DC

U2: 0 – 1 V DC

U3: 0 – 10 V DC

OUTPUT SPECIFICATIONS

With the input voltage code 6, U3 (0 % ≥ 0 V) and current,

the output goes below 0 % when the input is open.

INSTALLATION

Current consumption: Approx. 60 mA with voltage output 1

Approx. 90 mA with current output 1

Operating temperature: -5 to +55°C (23 to 131°F)

Operating humidity: 30 to 90 %RH (non-condensing)

Mounting: Standard Rack 10BXx

Weight: 220 g (0.49 lb)

PERFORMANCE in percentage of span

Accuracy: ±0.1 %

Temp. coefficient: ±0.015 %/°C (±0.008 %/°F)

Response time: ≤ 0.5 sec. (0 – 90 %)

Line voltage effect: ±0.1 % over voltage range

Insulation resistance: ≥ 100 MΩ with 500 V DC

Dielectric strength: 500 V AC @ 1 minute

(input to output 1 to output 2 to power)

1500 V AC @ 1 minute (input or output or power to ground)
