MODEL: 10JR

http://www.m-system.co.jp/

10JR SPECIFICATIONS

ES-0864 Rev.9 Page 2/3

Power input: Supplied from card-edge connector

Screw terminal: Nickel-plated steel

Housing material: Flame-resistant resin (black)

Isolation: Input to output 1 to output 2 to power

Overrange output: Approx. -10 to +120 % at 1 – 5 V

Linearization: Standard

Adjustments: Programming Unit (model: PU-2x); RTD type

(between Pt 100 and JPt 100 only), temp. range, zero and

span, simulating output, etc.

(Refer to the users manual of JXCON for the adjustments

configurable with JXCON.)

INPUT SPECIFICATIONS

Maximum leadwire resistance: 20 Ω per wire (3-wire)

Sensing current: 2 mA (Pt)

If not specified, the input range is shown below.

1: JPt 100 (JIS '89) 0 – 100°C

3: Pt 100 (JIS '89) 0 – 100°C

4: Pt 100 (JIS '97, IEC) 0 – 100°C

5: Pt 50 Ω (JIS '81) 0 – 200°C

6: Ni 508.4 Ω 0 – 100°C

INSTALLATION

Current consumption: Approx. 60 mA with voltage output 1

Approx. 90 mA with current output 1

Operating temperature: -5 to +55°C (23 to 131°F)

Operating humidity: 30 to 90 %RH (non-condensing)

Mounting: Standard Rack 10BXx

Weight: 220 g (0.49 lb)

PERFORMANCE in percentage of span

Accuracy: ±0.1 % or ±0.1°C (±0.18°F), whichever is greater

Temp. coefficient: ±0.015 %/°C (±0.008 %/°F)

Response time: ≤ 0.5 sec. (0 – 90 %)

Burnout response: ≤ 10 sec.

Line voltage effect: ±0.1 % over voltage range

Insulation resistance: ≥ 100 MΩ with 500 V DC

Dielectric strength: 500 V AC @ 1 minute

(input to output 1 to output 2 to power)

1500 V AC @ 1 minute (input or output or power to ground)
