Part Number:

0150180098

Status:

Active

Overview:

FFC Cable Jumpers, Premo-Flex Flat-Flexible Cable Jumpers

Description:

0.50mm Pitch Premo-Flex FFC Jumper with Ears, Opposite Side Contacts (Type D),

51.00mm Cable Length, Gold (Au) Plating, 10 Circuits

Documents:

Drawing (PDF)

Datasheet (PDF)

Product Specification 150180001-000 (PDF)

RoHS Certificate of Compliance (PDF)

General

Product Family

Cable

Series

15018

Comments

Opposite Side Contacts, Type D

Crimp Quality Equipment

Yes

Overview

FFC Cable Jumpers, Premo-Flex Flat-Flexible Cable

Jumpers

Product Name

Premo-Flex FFC Jumper

UPC

193264329441

Physical

Cable Length

51.00mm

Circuits (Loaded)

10

Contact Layout Type

D (opposite side)

Material - Plating Mating

Gold

Packaging Type

Bag

Pitch - Mating Interface

0.50mm

Temperature Range - Operating

-40° to +105°C

Wire Size AWG

N/A

Wire/Cable Type

Flat Flex Cable

Electrical

Current - Maximum per Contact

0.5A

Voltage - Maximum

60V AC

Material Info

Reference - Drawing Numbers

Product Specification

150180001-000

Sales Drawing

SD-15018-001-001

Series image - Reference only

EU ELV

Not Relevant

EU RoHS

China RoHS

Compliant

REACH SVHC

Not Contained Per -

D(2020)9139-DC (19

Jan 2021)

Halogen-Free

Status

Not Low-Halogen

For more information, please visit Contact US

China ROHS

Green Image

ELV

Not Relevant

RoHS Phthalates

Not Contained

Search Parts in this Series

15018 Series

Mates With

Easy-On FFC/FPC Connector 5051101092
