2SA1576A SOT-323

1 / 3

www.yfwdiode.com

Dongguan YFW Electronics Co, Ltd.

■

Features

●

Excellent hFE linearity

●

Complements the 2SC4081

■

Absolute Maximum Ratings Ta = 25℃

Parameter

Symbol

Rating

Unit

Collector - Base Voltage

VCBO

-60

Collector - Emitter Voltage

VCEO

-50

Emitter - Base Voltage

VEBO

-6

Collector Current - Continuous

IC

-150

mA

Collector Power Dissipation

PC

200

mW

Junction Temperature

TJ

150

Storage Temperature range

Tstg

-55 to 150

V

℃

■

Electrical Characteristics Ta = 25℃

Parameter

Symbol

Test Conditions

Min

Typ

Max

Unit

Collector- base breakdown voltage

VCBO

Ic= -50 μA， IE=0

-60

Collector- emitter breakdown voltage

VCEO

Ic= -1 mA，IB=0

-50

Emitter - base breakdown voltage

VEBO

IE= -50μA， IC=0

-6

Collector-base cut-off current

ICBO

VCB= -60 V , IE=0

-0.1

Emitter cut-off current

IEBO

VEB= -6V , IC=0

-0.1

Collector-emitter saturation voltage

VCE(sat) IC=-50 mA, IB=-5 mA

-0.5

Base - emitter saturation voltage

VBE(sat) IC=-50 mA, IB=-5 mA

-1.2

DC current gain

hFE

VCE= -6V, IC= -1mA

120

560

Collector output capacitance

Cob

VCB= -12V,IE=0, f=1MHz

4

5

pF

Transition frequency

fT

VCE= -12V, IC= -2mA,f=30MHz

140

MHz

V

uA

V

■

Classification of hfe

Type

2SA1576A-Q

2SA1576A-R

2SA1576A-S

Range

120-270

180-390

270-560

Marking

FQ

FR

FS

1

2

3

1.Base

2.Emitter

3.Collector

■

Simplified outline(SOT-323)

PNP Transistor

■
