PDS-002895 Rev 03

Luminus Devices, Inc. • T 408.708.7000 • www.luminus.com

1145 Sonora Court • Sunnyvale, CA 94086

SST-10-Red Product Datasheet

SST-10 Binning Structure

SST-10 Red LEDs are tested for luminous flux and chromaticity at a drive current of 350mA - 20ms single pulse and placed into one of the

following luminous flux (FF) and chromaticity (WW) bins:

Flux Bin (FF)

Minimum Flux (mW)

Maximum Flux (mW)

230

270

310

350

390

Flux Bins - Test condition=350mA, 250C, 20ms pulse

Chromaticity Bin (WW)

Minimum Dominant Wavelength (nm)

Maximum Dominant Wavelength (nm)

615

620

625

630

Dominant Wavelength Bins - Test condition=350mA, 250C, 20ms pulse

*Note:

Luminus maintains a +/- 6% tolerance on flux measurements.

Ordering Information

Products

Ordering Part Number

Description

SST-10-R-B90

SST-10-R-B90-xx123

High Power 1-mm2 Red LED in a 3535 surface mount package and a 90-de-

gree lens

SST-10-R-B130

SST-10-R-B130-xx123

High Power 1-mm2 Red LED in a 3535 surface mount package and a

130-degree lens
