isc Silicon NPN Power Transistors

ISCN200F

ELECTRICAL CHARACTERISTICS

TC=25℃ unless otherwise specified

SYMBOL

PARAMETER

CONDITIONS

MIN

TYP.

MAX

UNIT

V(BR)CEO

Collector-Emitter Breakdown Voltage

IC= 10mA ; RBE= ∞

V(BR)CBO

Collector-Base Breakdown Voltage

IC= 10μA; IE= 0

V(BR)EBO

Emitter-Base Breakdown Voltage

IE= 10μA; IC= 0

VCE(sat)

Collector-Emitter Saturation Voltage

IC= 2A; IB= 0.2A

1.0

VBE(sat)

Base-Emitter Saturation Voltage

IC= 2A; IB= 0.2A

1.2

ICBO

Collector Cutoff Current

VCB= 50V; IE= 0

hFE -1

DC current gain

IC= 1A ; VCE= 4V

100

300

hFE -2

DC current gain

IC=0.1A ; VCE= 4V

NOTICE：

ISC reserves the rights to make changes of the content herein the datasheet at any time without

notification. The information contained herein is presented only as a guide for the applications of

our products.

ISC products are intended for usage in general electronic equipment. The products are not designed

for use in equipment which require specialized quality and/or reliability, or in equipment which

could have applications in hazardous environments, aerospace industry, or medical field. Please

ISC makes no warranty or guarantee regarding the suitability of its products for any particular

purpose, nor does ISC assume any liability arising from the application or use of any products, and

specifically disclaims any and all liability, including without limitation special, consequential or

incidental damages.
