ADG936/ADG936-R

Rev. 0 | Page 4 of 16

ABSOLUTE MAXIMUM RATINGS

Table 2.

Parameter

Rating

–0.5 V to +4 V

Inputs to GND

Continuous Current

30 mA

Input Power

18 dBm

Operating Temperature Range

Industrial (B Version)

–40°C to +85°C

Storage Temperature Range

–65°C to +150°C

Junction Temperature

150°C

TSSOP Package

143°C/W

LFCSP Package

30.4°C/W

Lead Temperature, Soldering (10 s)

300°C

IR Reflow, Peak Temperature (<20 s)

235°C

ESD

1 kV

Stresses above those listed under Absolute Maximum Ratings

may cause permanent damage to the device. This is a stress

rating only and functional operation of the device at these or

any other conditions above those listed in the operational

sections of this specification is not implied. Exposure to

absolute maximum rating conditions for extended periods may

affect device reliability. Only one absolute maximum rating may

be applied at any one time.

Table 3. Truth Table

INx

RF1x

RF2x

0

Off

On

1

On

Off

ESD CAUTION

ESD (electrostatic discharge) sensitive device. Electrostatic charges as high as 4000 V readily accumulate on

the human body and test equipment and can discharge without detection. Although this product features

proprietary ESD protection circuitry, permanent damage may occur on devices subjected to high energy

electrostatic discharges. Therefore, proper ESD precautions are recommended to avoid performance

degradation or loss of functionality.
