PHOENIX CONTACT Inc., USA

Page 1 / 6

http://www.phoenixcon.com

Mar 9, 2010

Extract from the online

catalog



MVSTBR 2,5/12-ST

Order No.: 1792113

The figure shows a 10-position version of the product

http://eshop.phoenixcontact.de/phoenix/treeViewClick.do?UID=1792113





Plug component, Nominal current: 12 A, Nom. voltage: 250 V, Pitch:

5 mm, Number of positions: 12, Connection type: Screw connection,

Color: green



Commercial data

EAN

4017918044596

Pack

50 pcs.

Customs tariff

85366990

Weight/Piece

0.02618 KG

Catalog page information

Page 202 (CC-2009)

Product notes

WEEE/RoHS-compliant since:

01/01/2003

http://

www.download.phoenixcontact.com

Please note that the data given

here has been taken from the

online catalog. For comprehensive

information and data, please refer

to the user documentation. The

General Terms and Conditions of

Use apply to Internet downloads.

Technical data

Dimensions / positions

Pitch

5 mm

Dimension a

55 mm

Number of positions

12

Screw thread

M3
