-160

-150

-140

-130

-120

-110

-100

-90

-80

-70

-60

1000

10000

100000

1000000

CRO2117A

Digital Radio Equipment

Fixed Wireless Access

Satellite Communication Systems

5

20

3±2

2117

0.5-4.5

7

-115

-15

<0.5

<0.5

50

50

-40 to 85

Oscillation Frequency Range

Phase Noise @ 10 kHz offset (1 Hz BW, typ.)

Harmonic Suppression (2nd, typ.)

Tuning Voltage

Tuning Sensitivity (avg.)

Power Output

Load Impedance

Input Capacitance (max.)

Pushing

Pulling (14 dB Return Loss, Any Phase)

Operating Temperature Range

Package Style

MINI-16

MHz

dBc/Hz

dBc

Vdc

MHz/V

dBm

pF

MHz/V

MHz

°C

Vdc

mA

Supply Voltage (Vcc, nom.)

Supply Current (Icc, typ.)

All specifications are typical unless otherwise noted and subject to change without notice.

PHASE NOISE (1 Hz BW, typical)

© Z-Communications, Inc.

All rights reserved

Page 1

VOLTAGE CONTROLLED OSCILLATOR

Ω

FEATURES

APPLICATIONS

PERFORMANCE SPECIFICATIONS

VALUE

UNITS

POWER SUPPLY REQUIREMENTS

APPLICATION NOTES

2117 2118

-

MHz

• Frequency Range:

• Tuning Voltage:

0.5-4.5 Vdc

- Style Package

MINI-16

•

•

•

•

A1

Rev

•

AN-100/1 : Mounting and Grounding of VCOs

•

AN-102 : Proper Output Loading of VCOs

•

AN-107 : How to Solder Z-COMM VCOs

NOTES:

9939 Via Pasar • San Diego, CA 92126

TEL (858) 621-2700 FAX (858) 621-2722

- 2118

OFFSET (Hz)
