Cree P4 LED

CP41A-PDS

CP41A-PFS

CP41A-PHS

MECHANICAL DIMENSIONS

Alldimensionsareinmm.Toleranceis±0.25mmunlessotherwisenoted.

An epoxy meniscus extend about 1.5 mm down the leads.

All metal burr dimension is 0.2 mm max.

RoHS Compliance

The levels of environmentally sensitive, persistent biologically toxic (PBT), persistent organic pollutants (POP), or other-

wise restricted materials in this product are below the maximum concentration values (also referred to as the threshold

limits) permitted for such substances, or are used in an exempted application, in accordance with EU Directive 2002/95/

EC on the restriction of the use of certain hazardous substances in electrical and electronic equipment (RoHS), as

amended through April 21, 2006.

Vision Advisory Claim

Users should be cautioned not to stare at the light of this LED product. The bright light can damage the eye.

NOTES

CP41A-PDS:

CP41A-PFS:
