0786-CPD-50383

Supply

230 V AC / 50 Hz / 120 VA

Stand-by power

5.8 W

Output

24 V DC / 4 A

Mode of operation monitoring

Continuous duty

Mode of operation Alarm / Ventilation

Short-time duty 30 % duty cycle

Temperature range

-5 °C ... +40 °C

Line / Group

1 / 1

Battery type

Typ 2 (2x)

Type

Art. No.

Type of

protection

W x H x D

Weight

Remark

ZP-RZN 4404-K V2

30.102.23

2.00 kg

With alarm devices = Akku Typ 8 (2x)

RZN 44xx-K/M

30.104.70

Variable equipment possible

GEH-S-RWA

30.105.30

IP 54

400 x 300 x 120 mm

7.25 kg

Sheet steel housing

GEH-KST

63.600.81

IP 30

310 x 310 x 100 mm

1.40 kg

Plastic housing

RZN 4404-K V2

External control

Line

Fire detector

SHEVoperationpanel

Rain detector

Ventilation button

Drive

Group

Article also available with the following permissions under other article

numbers. Technical data may deviate.

Batteries must be ordered separately.

Example of application

Design

Technical data

Approvals / Certificates

Find out about permission details from your D+H Partner

Status 01/2018
