Mechanical characteristics

Conductor cross-section

1.5 mm²

Connection cross-section AWG

16

Stripping length of the individual wire

7.5 mm (9.5 mm at HC-M-HV...)

Insertion/withdrawal cycles

≥ 500

General characteristics

Type

Individual male contact

Connection method

Crimp connection

Connection

for HC-M-06, HC-M-HV, HC-M-08, HC-M-20, HC-A, HC-BB, HC-

B and HC-HV contact carriers. The quality of a crimp connection

is determined by the DIN EN 60 352-2.

Material data

Contact material

Copper alloy

Contact surface material

hard-silver plated

Certificates / Approvals

Certification

GOST, UL

Accessories

Item

Designation

Description

Tools

1676734

CK1,6/2,5-MWZ

Assembly tool, for CK 1.6... crimp contacts for small conductor

cross sections

1662722

CK2,5-EWZ

Contact removal tool, for turned and rolled CK- 2.5-... contacts

1687419

CRIMPFOX-1,6/2,5-ED-4,0

Crimping pliers, for turned contacts, CK 1.6 ED... and CK 2.5 ED...
