ADG904/ADG904-R

Rev. 0 | Page 4 of 16

ABSOLUTE MAXIMUM RATINGS

Table 2. TA = 25°C, unless otherwise noted

Parameter

Rating

VDD to GND

–0.5 V to +4 V

Inputs to GND

–0.5 V to VDD + 0.3 V1

Continuous Current

30 mA

Input Power

18 dBm

Operating Temperature Range

Industrial (B Version)

–40°C to +85°C

Storage Temperature Range

–65°C to +150°C

Junction Temperature

150°C

TSSOP Package

θJA Thermal Impedance

143°C/W

Lead Temperature, Soldering (10 sec)

300°C

IR Reflow, Peak Temperature (<20 sec)

235°C

ESD

1 kV

Stresses above those listed under Absolute Maximum Ratings

may cause permanent damage to the device. This is a stress

rating only and functional operation of the device at these or

any other conditions above those listed in the operational

sections of this specification is not implied. Exposure to

absolute maximum rating conditions for extended periods may

affect device reliability. Only one absolute maximum rating may

be applied at any one time.

Table 3. Truth Table

ON Switch2

None

RF1

RF2

RF3

RF4

1 RFx Off Port Inputs to Ground = –0.5 V to VDD – 0.5 V.

2 OFF Switches have:

50 Ω termination to GND (ADG904).

Shunt to GND (ADG904-R).

ESD CAUTION

ESD (electrostatic discharge) sensitive device. Electrostatic charges as high as 4000 V readily accumulate on

the human body and test equipment and can discharge without detection. Although this product features

proprietary ESD protection circuitry, permanent damage may occur on devices subjected to high energy

electrostatic discharges. Therefore, proper ESD precautions are recommended to avoid performance

degradation or loss of functionality.
