07/23/2018   Page 3 / 5

Relay Module - PLC-RSP- 12DC/21AU - 2967442

Technical data

Connection data input side

Connection method

Spring-cage connection

Stripping length

8 mm

Conductor cross section solid

0.14 mm² ... 2.5 mm²

Conductor cross section flexible

0.14 mm² ... 2.5 mm²

Conductor cross section AWG

26 ... 14

Connection data output side

Connection name

Contact side

Connection method

Spring-cage connection

Stripping length

8 mm

Conductor cross section solid

0.14 mm² ... 2.5 mm²

Conductor cross section flexible

0.14 mm² ... 2.5 mm²

Conductor cross section AWG

26 ... 14

General

Test voltage relay winding/relay contact

4 kV AC (50 Hz, 1 min.)

Operating mode

100% operating factor

Degree of protection

IP20 (Relay base)

Mechanical service life

Mounting position

any

Assembly instructions

In rows with zero spacing

Standards and Regulations

Connection in acc. with standard

CUL

Designation

Standards/regulations

Standards/regulations

IEC 60664

EN 50178

Degree of pollution

3

Overvoltage category

III

Flammability rating according to UL 94

V0

Environmental Product Compliance

REACh SVHC

Lead 7439-92-1

China RoHS

Environmentally Friendly Use Period = 50

For details about hazardous substances go to tab “Downloads”,

Category “Manufacturer's declaration”

Drawings
