3 / 28 page  Data Sheet ADL5240 Rev. A | Page 3 of 28 SPECIFICATIONS VDD = 5 V, VCC = 5 V, TA = 25oC Table 1. Parameter Test Conditions/Comments Min Typ Max Unit OVERALL FUNCTION Frequency Range 100 4000 MHz AMPLIFIER FREQUENCY = 150 MHz Using the AMPIN and AMPOUT pins Gain 17.6 dB vs. Frequency ±50 MHz ±1.0 dB vs. Temperature −40°C ≤ TA ≤ +85°C ±0.04 dB vs. Supply 4.75 V to 5.25 V ±0.04 dB Input Return Loss S11 −10.4 dB Output Return Loss S22 −7.7 dB Output 1 dB Compression Point 18.3 dBm Output Third-Order Intercept ∆f = 1 MHz, POUT = 4 dBm/tone 30.0 dBm Noise Figure 2.8 dB AMPLIFIER FREQUENCY = 450 MHz Using the AMPIN and AMPOUT pins Gain 20.3 dB vs. Frequency ±50 MHz ±0.11 dB vs. Temperature −40°C ≤ TA ≤ +85°C ±0.36 dB vs. Supply 4.75 V to 5.25 V ±0.01 dB Input Return Loss S11 −18.3 dB Output Return Loss S22 −15.7 dB Output 1 dB Compression Point 20.2 dBm Output Third-Order Intercept ∆f = 1 MHz, POUT = 4 dBm/tone 39.0 dBm Noise Figure 2.9 dB AMPLIFIER FREQUENCY = 748 MHz Using the AMPIN and AMPOUT pins Gain 20.6 dB vs. Frequency ±50 MHz ±0.01 dB vs. Temperature −40°C ≤ TA ≤ +85°C ±0.31 dB vs. Supply 4.75 V to 5.25 V ±0.01 dB Input Return Loss S11 −25.7 dB Output Return Loss S22 −23.7 dB Output 1 dB Compression Point 20.2 dBm Output Third-Order Intercept ∆f = 1 MHz, POUT = 4 dBm/tone 40.0 dBm Noise Figure 2.7 dB AMPLIFIER FREQUENCY = 943 MHz Using the AMPIN and AMPOUT pins Gain 19.0 20.5 22.0 dB vs. Frequency ±18 MHz ±0.01 dB vs. Temperature −40°C ≤ TA ≤ +85°C ±0.27 dB vs. Supply 4.75 V to 5.25 V ±0.01 dB Input Return Loss S11 −30.3 dB Output Return Loss S22 −24.8 dB Output 1 dB Compression Point 18.5 20.1 dBm Output Third-Order Intercept ∆f = 1 MHz, POUT = 4 dBm/tone 40.0 dBm Noise Figure 2.7 dB |
|
