34.0

(1.34)

38.4

(1.51)

2.0 ± 0.5

(.079 ± .020)

50.0

(1.969)

330

(12.99)

DIA.

13.0 ± 0.5

(.512 ± .020)

DIA.

13.0 ± 0.5

(.512 ± .020)

DIA.

21.0 ± 0.8

(.827 ± .031)

EMBOSSED

CARRIER

EMBOSSED

CAVITY

0.10

(.004)

THICKNESS

MAX.

Packaging Specifications

22.4 ± 0.1

(.882 ± .004)

32.0 ± 0.3

(1.26 ± .012)

9.0 ± 0.1

(.354 ± .004)

15.5 ± 0.1

(.610 ± .004)

20.0 ± 0.1

(.787 ± .004)

4.0 ± 0.1

(.157 ± .004)

1.55 ± 0.05

(.061 ± .002)

2.0

(.079)

MIN.

8.45 ± 0.1

(.333 ± .004)

0.5 ± 0.05

(.020 ± .002)

QTY: 250 PCS. PER REEL

SDR2207 Series - SMD Power Inductors

DIMENSIONS:

MM

(INCHES)

REV. 02/05

Specifications are subject to change without notice.

Customers should verify actual device performance in their specific applications.

Soldering Profile

0

50

100

150

200

250

300

0

50

100

150

200

250

300

Time (seconds)

<1> Max. of 30 seconds > 200 °C

<2> Max. of 10 seconds at 230 °C

230 °C

<2>

<1>

120 - 150 seconds

Ramp-up

4 °/second maximum

Ramp-down

5 °C/second maximum
