Data Sheet

AD8364

Rev. C | Page 7 of 44

ABSOLUTE MAXIMUM RATINGS

Table 2.

Parameter

Rating

Supply Voltage VPSA, VPSB, VPSR

5.5 V

PWDN, VSTA, VSTB, ADJA, ADJB,

FBKA, FBKB

0 V, 5.5 V

Input Power (Referred to 50 Ω)

23 dBm

Internal Power Dissipation

600 mW

θJA

39.8°C/W1, 2

θJC

3.9°C/W2

θJB

22.8°C/W2

ΨJT

0.4°C/W1, 2

Maximum Junction Temperature

125°C

Operating Temperature Range

−40°C to +85°C

Storage Temperature Range

−65°C to +150°C

Still air.

All values are modeled using a standard 4-layer JEDEC test board with the

pad soldered to the board and thermal vias in the board.

Stresses at or above those listed under Absolute Maximum

Ratings may cause permanent damage to the product. This is a

stress rating only; functional operation of the product at these

or any other conditions above those indicated in the operational

section of this specification is not implied. Operation beyond

the maximum operating conditions for extended periods may

affect product reliability.

ESD CAUTION
