PRODUCT
DATASHEET
CS15767_HB-2X2MX-8-M
HB-2X2MX-8-M
~30° wide beam. New revision.
TECHNICAL SPECIFICATIONS:
Dimensions
90x90 mm
Height
16.4 mm
Fastening
screw
Colour
clear
Box size
480 x 280 x 300 mm
Box weight
8.3 kg
Quantity in Box
156 pcs
ROHS compliant
yes
MATERIAL SPECIFICATIONS:
Component
Type
Material
Colour
HB-2X2MX-8-M
Lens array
PMMA
clear
STRADA-2X2MX-8-SEAL
Seal
Silicone
clear
Last update: 11/09/2017
Subject to change without prior notice
1/6
LEDiL is a registered trademark of LEDiL Oy in the European Union, USA, and certain other countries.
