2600 MHz, VPOS = 3 V

Matched for optimal noise figure, external matching circuit included.

–10

–20

–5

–15

–25

–30

2100

2200

2300

2600

2700

2400

2500

2800

2900

FREQUENCY (MHz)

S11

S21

S12

S22

Figure 39. Typical S-Parameters, Log Magnitude

2500 2520

2560

2600

2640

2680

2540

2580

2620

2660

2700

FREQUENCY (MHz)

GAIN

P1dB

OIP3

NOISE FIGURE

Figure 40. Noise Figure, Gain, OIP3, and P1dB vs. Frequency

2.0

1.8

1.6

1.4

1.2

1.0

0.8

0.6

0.4

0.2

2500 2520 2540 2560 2580 2600 2620 2640 2660 2680 2700

FREQUENCY (MHz)

+25°C

+85°C

–40°C

Figure 41. Noise Figure vs. Temperature

2.0

1.8

1.6

1.4

1.2

1.0

0.8

0.6

0.4

0.2

2500 2520 2540 2560 2580 2600 2620 2640 2660 2680 2700

FREQUENCY (MHz)

Figure 42. Noise Figure vs. Frequency at 25°C, Multiple Devices

15.5

15.0

14.5

14.0

13.5

13.0

12.5

12.0

11.5

11.0

2500 2520 2540 2560 2580 2600 2620 2640 2660 2680 2700

FREQUENCY (MHz)

+85°C

+25°C

–40°C

GAIN

P1dB

OIP3

–40°C

+85°C

Figure 43. Gain, OIP3, and P1dB vs. Temperature

–6

–2

–4

POUT PER TONE (dBm)

+85°C

+25°C

–40°C

Figure 44. OIP3 vs. Output Power (POUT) and Temperature
