LRTB-R48G Folha de dados(PDF) 1 Page - OSRAM GmbH |
|
|
|||||||||||||||||||||||||||||
LRTB-R48G Folha de dados(HTML) 1 Page - OSRAM GmbH |
|
|
1 / 29 page  LRTB R48G Multi CHIPLED Data Sheet Version 1.8 2018-05-14 1 Das Bauteil ist speziell für den Einsatz in Vollfarb-Videowänden entwickelt worden. Die 4-lead common anode Technologie läßt eine unahängige Ansteuerung aller Chips zu und bietet dadurch eine additive Farbmischung. Durch die kompakten Gehäuseabmaße ist es bestens für Videowände mit hoher Auflösung und geringem Pixelabstand geeignet. Merkmale • Gehäusetyp: SMT Gehäuse, Harz Verguss • Farbe: Rot/True Grün/Blau, 623 nm (rot), 530 nm (true grün), 471 nm (blau) • Abstrahlwinkel: Lambertscher Strahler (120°) • Chiptechnologie: InGaAlP (rot), InGaN (true grün, blau) • Lötmethode: Reflow lötbar • Vorbehandlung: nach JEDEC Level 4 • ESD-Festigkeit: ESD-sensitiv Anwendungen • Videoleinwände im Innenbereich • Vollfarb-Displays This device is especially designed for full color video walls. The 4-lead common anode technology admits an additive mixture of color stimuli by independent driving of each chip. Very compact package size fits best for high resolution narrow pitch video walls. Features • package: SMT package, epoxy resin • color: red/true green/ blue, 623 nm (red), 530 nm (true green), 471 nm (blue) • viewing angle: Lambertian Emitter (120°) • chiptechnology: InGaAlP(red), InGaN (true green, blue) • soldering methods: reflow solderable • preconditioning: acc. to JEDEC Level 4 • ESD-withstand voltage: sensitive device Applications • Indoor Video Walls • full color display |
