OP550, OP552, OP555, OP560, OP565,

OP750 Series

Issue A

08/2016

Page 2

OPTEK Technology, Inc.

1645 Wallace Drive, Carrollton, TX 75006|Ph: +1 972 323 2200

www.optekinc.com | www.ttelectronics.com

OP555, OP565 (A, B, C, D)

OP550, OP552, OP560, OP750, OP770 (A, B, C, D)

Pin #

Sensor

1

Emitter

2

Collector

1

2

OP555 - CONTAINS POLYSULFONE

To avoid stress cracking, we suggest using

ND Industries’ Vibra-Tite for thread-locking.

Vibra-Tite evaporates fast without causing structural failure in

OPTEK'S molded plastics.

INCHES

[MILLIMETERS]

DIMENSIONS ARE IN:

INCHES

[MILLIMETERS]

DIMENSIONS ARE IN:

Notes:

1. RMA flux is recommended. Duration can be extended to 10 seconds maximum when flow soldering. A maximum 20 grams force may be applied

to the leads when soldering.

2. For OP550, OP560, OP555 and OP565, derate linearly 1.33 mW/° C above 25° C. For OP552, derate linearly 1.25 mW/° C above 25° C.

3. For all phototransistors in this series, the light source is an unfiltered GaAs LED with a peak emission wavelength of 935 nm. For OP550 and

OP555 only, a radiometric intensity level that varies less than 10% over the entire lens surface of the phototransistor being tested applies.

(0.040 T
