Cree 5-mm Oval LED

C566T-RFS/AFS

• Tolerance of measurement of luminous intensity is ±15%

• Tolerance of measurement of dominant wavelength is ±1 nm

Red

Bin Code

Min.(mcd) Max.(mcd)

R0

550

770

S0

770

1100

T0

1100

1520

Red

Bin Code

Min.(nm)

Max.(nm)

RC

620

535

Amber

Bin Code

Min.(mcd) Max.(mcd)

R0

550

770

S0

770

1100

T0

1100

1520

Amber

Bin Code

Min. (nm)

Max. (nm)

A2

584

587

A3

587

590

A4

590

593

A5

593

596

INTENSITY BIN LIMIT (I

COLOR BIN LIMIT (I
