Configuration

• Connector 1: N Female Bulkhead

• Connector 2: BNC Male

• Cable Type: RG174

.

Electrical Specifications

Description

Minimum

Typical

Maximum

Units

Frequency Range

DC

1,000

MHz

VSWR

1.4:1

Velocity of Propagation

66

%

Capacitance

31.1 [102.03]

pF/ft [pF/m]

.

Specifications by Frequency

Description

F1

F2

F3

F4

F5

Units

Frequency

50

100

250

500

1,000

MHz

Insertion Loss (Max.)

1.04

1.08

1.14

1.21

1.32

dB/ft

3.41

3.54

3.74

3.97

4.33

dB/m

Insertion Loss (Typ.)

0.242

0.284

0.337

0.412

0.52

dB/ft

0.79

0.93

1.11

1.35

1.71

dB/m

VSWR (Max.)

1.4:1

1.4:1

1.4:1

1.4:1

1.4:1

Return Loss (Max.)

15.56

15.563

15.563

15.563

15.563

dB

.

Mechanical Specifications

Cable Assembly

Diameter

0.807 in [20.5 mm]

.

Cable

Cable Type

RG174

Impedance

50 Ohms

Inner Conductor Type

Stranded

Inner Conductor Material and Plating

Copper Clad Steel, Silver

Click the following link (or enter part number in “SEARCH” on website) to obtain additional part information including price,

inventory and certifications: N Female Bulkhead to BNC Male Cable Using RG174 Coax PE3C3474

PE3C3474 REV 1.0

N Female Bulkhead to BNC Male Cable Using RG174 Coax

RF Cable Assemblies Technical Data Sheet

PE3C3474
