MB96340 Series
Document Number: 002-04579 Rev. *A
Page 95 of 109
14.7.1
Low Voltage Detector Operation
In the following figure, the occurrence of a low voltage condition is illustrated. For a detailed description of the reset and startup
behavior, please refer to the corresponding hardware manual chapter.
Voltage [V]
Time [s]
VCC
VDLx, Min
VDLx, Max
dV
dt
Low Voltage Reset Assertion
Normal Operation
Power Reset Extension Time
