The PEWCT1046 is a 40 dB WR-34 four port crossguide coupler with one coupled port terminated (making it a three port

coupler) and a coax adapter on the opposite coupled port. This coupler can be mounted directly into the waveguide signal

path, connected via coax to allow signal sampling /monitoring. The coupler has a typical VSWR of 1.05:1 and are made of

bronze with brass UG-1530/U Square Cover flanges. The PEWCT1046 is part of a family of cross guide couplers offered

by Pasternack with coupling values ranging from 20 to 50 dB. There is also a full family of top wall (broad wall) couplers.

For the three port version of this coupler (terminated but no coax adapter) please see the PEWCT1002. For the four port

version of this coupler (no termination, no coax adapter) please see the PEWCP1037.

Features

• Three Port

• Crossguide Waveguide Coupler

• Terminated

• 40 dB Nominal Coupling Level

• 2.92mm Female Coax Adapter

• 22 GHz to 33 GHz Frequency Range

• Waveguide Body made of Bronze with Brass Flanges

• Low VSWR

Applications

• Test Benches

• Radar

• Satellite

• Microwave Radio

• Attenuation Measurements

• Power Measurements

• Source Leveling

Electrical Specifications

Description

Minimum

Typical

Maximum

Units

Frequency Range

22

33

GHz

Impedance

50

Ohms

Coupler

Nominal Coupling Level

40

dB

Directivity

25

dB

Insertion Loss

0.1

dB

Main Line VSWR

1.05:1

Termination

Input Power (CW)

1

Watts

Waveguide to Coax Adapters

VSWR

1.25:1

.

Mechanical Specifications

.

Interface

Waveguide Size

WR-34

Click the following link (or enter part number in “SEARCH” on website) to obtain additional part information including price,

inventory and certifications: WR-34 Waveguide 40 dB Crossguide Coupler, UG-1530/U Square Cover Flange, 2.92mm

Female Coupled Port, 22 GHz to 33 GHz, Bronze PEWCT1046

PEWCT1046 REV 1.0

WR-34 Waveguide 40 dB Crossguide Coupler, UG-

1530/U Square Cover Flange, 2.92mm Female

Coupled Port, 22 GHz to 33 GHz, Bronze

Waveguide Couplers Assemblies Technical Data

PEWCT1046
