NPN

Plastic-Encapsulate

Transistors

Features

•

Small Reverse Transfer Capacitance

•

Low Noise Figure

omponents

20736 Marilla

Street Chatsworth



 !"#

$%    !"#

Revision:

A

20

15/05/18

1 of

3

•

Epoxy meets UL 94 V-0 flammability rating

•

Moisture Sensitivity Level 1

℃ unless otherwise noted)

Symbol

ParameterValue

Unit

Collector-Base Voltage

40

V

Collector-Emitter Voltage

30

V

Emitter-Base Voltage

4

V

Collector Current -Continuous

20

mA

Collector Power Dissipation

200

mW

Junction Temperature

150

℃

Storage Temperature

-55-150

℃

•

Lead Free Finish/Rohs Compliant ("P"Suffix designates

Compliant. See ordering information)

Micro Commercial Components

M C C

TM

TO-92S

INCHES

MM

DIM

MIN

MAX

MIN

MAX

NOTE

A

.056

.064

1.42

1.62

B

B

.154

.161

3.90

4.10

C

.120

.128

3.05

3.25

C

D

E

DIMENSIONS

1

2

3

1

2

3

BENT LEAD

STRAIGHT LEAD

BULK PACK

AMMO PACK

.050

1.27

D

.086

.110

2.20

2.80

E

.096

.104

2.44

2.64

.173

.220

4.40

5.60

L

.594

.610

15.10

15.50

* For ammo packing detailed specification, click here to visit our website

of product packaging for details.

Straight Lead

Bent Lead

Straight Lead

Bent Lead

1. EMITTER

2. COLLECTOR

3. BASE

2SC2668-Y

2SC2668-O

2SC2668-R

•

Halogen free available upon request by adding suffix "-HF"
