5. General Specification:

a) Operating Temp. : -40°C ~ +125°C

b) Storage Temp. : -40°C ~ +125°C

c) Rated Current will cause the inductance drop within 10%

6. Electrical Characteristics

Part No

Inductance

(uH)

Tolerance

Q Min.

Test Frequency

(MHz)

SRF

(MHz) Min.

DCR (Ω)

Max.

IDC

(mA)

Max.

WI453232-R10 F

0.10

M

35

25.2

300

0.18

800

WI453232-R12 F

0.12

M

35

25.2

280

0.20

770

WI453232-R15 F

0.15

M

35

25.2

250

0.22

730

WI453232-R18 F

0.18

M

35

25.2

220

0.24

700

WI453232-R22 F

0.22

M

40

25.2

200

0.25

665

WI453232-R27 F

0.27

M

40

25.2

180

0.26

635

WI453232-R33 F

0.33

M

40

25.2

165

0.28

605

WI453232-R39 F

0.39

M

40

25.2

150

0.30

575

WI453232-R47 F

0.47

M

40

25.2

145

0.32

545

WI453232-R56 F

0.56

M

40

25.2

140

0.36

520

WI453232-R68 F

0.68

M

40

25.2

135

0.40

500

WI453232-R82 F

0.82

M

40

25.2

130

0.45

475

WI453232-1R0 F

1.0

K

50

7.96

100

0.50

450

WI453232-1R2 F

1.2

K

50

7.96

80

0.55

430

WI453232-1R5 F

1.5

K

50

7.96

70

0.60

410

WI453232-1R8 F

1.8

K

50

7.96

60

0.65

390

WI453232-2R2 F

2.2

K

50

7.96

55

0.70

380

WI453232-2R7 F

2.7

K

50

7.96

50

0.75

370

WI453232-3R3 F

3.3

K

50

7.96

45

0.80

355

WI453232-3R9 F

3.9

K

50

7.96

40

0.90

330

WI453232-4R7 F

4.7

K

50

7.96

35

1.00

315

WI453232-5R6 F

5.6

K

50

7.96

33

1.10

300

WI453232-6R8 F

6.8

K

50

7.96

27

1.20

285

WI453232-8R2 F

8.2

K

50

7.96

25

1.40

270

WI453232-100 F

10

K

50

2.52

20

1.60

250

WI453232-120 F

12

K

50

2.52

18

2.00

225

WI453232-150 F

15

K

50

2.52

17

2.50

200
