TECHNICAL DATA SHEET

TECHNICAL DATA SHEET

1

N Male to N Female Cable 24 Inch Length Using 1/4 inch Superflexible Coax

Configuration

Connector 1

N Male

Connector 2

N Female

Cable Type

1/4” Superflexible

Impedance, Ohms

50

Mechanical Specifications

Cable Assembly

Cable Type

1/4” Superflexible

Temperature

Temperature Operating Range, deg C

-55 to +85

Size

Length, in [mm]

24 [609.6]

Diameter, in [mm]

0.74 [18.8]

.

Weight, lbs [g]

0.448 [203.21]

Cable Color

Black

One Time Minimum Bend Radius, in [mm]

0.5 [12.7]

Repeated Minimum Bend Radius, in [mm]

1 [25.4]

Cable

No of Shields

1

Dielectric Type

PE (F)

Jacket Material

PE

Jacket Diameter, in [mm]

0.303 [7.7]

Connector 1

Type

N Male

Configuration

Straight

Mating Cycles

500

Inner Conductor Material and Plating

Spring Copper, Silver

Outer Conductor Material and Plating

Brass, Tri-Metal

Hex Size, mm

19

Torque, in-lbs [Nm]

15 [1.7]

Dielectric Type

PTFE

Connector 2

Type

N Female

Configuration

Straight

Mating Cycles

500

Inner Conductor Material and Plating

Spring Copper, Silver

Click the following link (or enter part number in “SEARCH” on website) to obtain additional part information including price,

inventory and certifications: N Male to N Female Cable 24 Inch Length Using 1/4 inch Superflexible Coax PE3C0125-24

PE3C0125-24 REV

PE3C0125-24

N Male to N Female Cable 24 Inch Length

Using 1/4 inch Superflexible Coax
