MBR360D Folha de dados(PDF) 1 Page - JILIN SINO-MICROELECTRONICS CO., LTD. |
|
|
|||||||||||||||||||||||||||||
MBR360D Folha de dados(HTML) 1 Page - JILIN SINO-MICROELECTRONICS CO., LTD. |
|
|
1 / 9 page  R 版本(Rev.)：201510D 1/9 肖特基势垒二极管 SCHOTTKY BARRIER DIODE MBR360 订 货 型 号 Order codes 印 记 Marking 封 装 Package 无卤素 Halogen Free 包 装 Packaging 器件重量 Device Weight MBR360DR MBR360 DO-201AD 是 YES 编带 Tape 1.1g(approx.) MBR360D MBR360 DO-201AD 否 NO 编带 Tape 1.1g(approx.) MBR360XR MBR360 SMA 是 YES 编带 Tape 0.071g(approx.) MBR360X MBR360 SMA 否 NO 编带 Tape 0.071g(approx.) MBR360KR MBR360 SMB 是 YES 编带 Tape 0.096g(approx.) MBR360K MBR360 SMB 否 NO 编带 Tape 0.096g(approx.) MBR360PR MBR360 SMC 是 YES 编带 Tape 0.24g(approx.) MBR360P MBR360 SMC 否 NO 编带 Tape 0.24g(approx.) MBR360M2R MBR360 TO-126-2L 是 YES 袋装 Bag 0.7g(approx.) MBR360M2 MBR360 TO-126-2L 否 NO 袋装 Bag 0.7g(approx.) MBR360M2R MBR360 TO-126-2L 是 YES 条管 Tube 0.7g(approx.) MBR360M2 MBR360 TO-126-2L 否 NO 条管 Tube 0.7g(approx.) 主要参数 MAIN CHARACTERISTICS IF(AV) 3A VRRM 60 V Tj 150 ℃ VF(max) 0.58V （@Tj=125℃） 用途 l 低压、高频整流 l 低压续流电路和保护电 路 APPLICATIONS l Low voltage, high frequency rectifier l Free wheeling diodes, polarity protection applications 产品特性 l轴向结构 l低功耗，高效率 l良好的高温特性 l有过压保护环，高可靠性 l环保（RoHS）产品 FEATURES lAxial Lead Rectifier lLow power loss, high efficiency lHigh Operating Junction Temperature lGuard ring for overvoltage protection，High reliability lRoHS product 订货信息 ORDER MESSAGE 封装 Package DO-201AD SMA SMB SMC TO-126-2L |
