Configuration

• N Female Connector

• MIL-STD-348A

• 50 Ohms

• Straight Body Geometry

• RG59, RG62, RG71 Interface Type

• Clamp/Solder Attachment

Features

• Max. Operating Frequency 1,000 MHz

• Good VSWR of 1.8:1

• Gold Plated Brass Contact

Applications

• General Purpose Test

• Custom Cable Assemblies

.

Description

Pasternack’s PE4330 type N female connector with clamp/solder attachment for RG59, RG62 and RG71 is part of our full line

of RF components available for same-day shipping. Our type N female connector operates up to a maximum frequency of

1,000 MHz and offers good VSWR of 1.8:1.

Our type N female connector PE4330 datasheet specifications and drawing with dimensions are shown below in this PDF.

Pasternack’s broad catalog of RF, microwave and millimeter wave connectors allows designers to configure and customize

their signal connections however they like. Whether the need is to provide an I/O for a board design, or simply create a custom

cable assembly configuration, Pasternack has the right connector for the job. Pasternack can also expertly build your custom

cable assemblies for you and ship same-day.

Electrical Specifications

Description

Minimum

Typical

Maximum

Units

Frequency Range

DC

1,000

MHz

VSWR

1.8:1

Operating Voltage (AC)

1,000

Vrms

.

Mechanical Specifications

Size

Length

1.43 in [36.32 mm]

Width/Dia.

0.625 in [15.88 mm]

.

Weight

0.071 lbs [32.21 g]

.

Click the following link (or enter part number in “SEARCH” on website) to obtain additional part information including price,

inventory and certifications: N Female Connector Clamp/Solder Attachment for RG59, RG62, RG71 PE4330

PE4330 REV 1.3

N Female Connector Clamp/Solder

Attachment for RG59, RG62, RG71

RF Connectors Technical Data Sheet

PE4330
