Product Description
The HMJ9 is a high dynamic range, GaAs FET mixer. As an upconverter, this active FET mixer realizes a typical third order intercept point of +35 dBm at an LO drive level of +17 dBm. The HMJ9 comes in a low cost, J-lead package. Typical applications include frequency up/down conversion for receivers and transmitters used in cellular communications systems.

Product Features
• +35 dBm IIP3
• No External Matching Elements Required
• RF 860-900 MHz
• LO 1140-1160 MHz
• IF 250-280 MHz
• +17 dBm Drive Level
• +3V Bias (23 mA)
• Low Cost Surface Mount J-Lead Package
