PhotoMOS RELAYS

FEATURES
1. Current Limit Function
To control an over current from flowing, the current limit function has been realized. It keeps an output current at a constant value when the current reaches a specified current limit value.
2. Enhancing the capability of surge resistance between output terminals The current limit function controls the ON time surge current to enhance the capability of surge resistance between output
terminals.
3. Reinforced insulation 5,000 V type
More than 0.4 mm internal insulation distance between inputs and outputs. Conforms to EN41003, EN60950 (reinforced insulation).
4. Compact 8-pin DIP size
The device comes in a compact  (W)6.4 × (L)9.86 × (H) 3.2mm (W).252× (L).388×(H).126inch, 8-pin DIP size (through hole terminal type)
5. Applicable for 2 Form A use as well as two independent 1 Form A use.
6. Controls low-level analog signals
7. High sensitivity, high speed response.
Can control a maximum 0.12 A load current with a 5 mA input current. Fast operation speed of 0.5ms (typ.)
8. Low-level off state leakage current

TYPICAL APPLICATIONS
• Telephone equipment
• Modem
