Mitsubishi microcomputers

M16C / 62A Group

SINGLE-CHIP 16-BIT CMOS MICROCOMPUTER

Timing (Vcc = 3V)

194

Timing requirements (referenced to VCC = 3V, VSS = 0V at Ta = – 20oC to 85oC / – 40oC to 85oC (*)

unless otherwise specified)

* : Specify a product of -40

°C to 85°C to use it.

VCC = 3V

Standard

Max.

Min.

Parameter

Symbol

Unit

tc(TB)

TBiIN input cycle time (counted on one edge)

150

tw(TBH)

TBiIN input HIGH pulse width (counted on one edge)

tw(TBL)

TBiIN input LOW pulse width (counted on one edge)

tw(TBH)

TBiIN input HIGH pulse width (counted on both edges)

160

tw(TBL)

TBiIN input LOW pulse width (counted on both edges)

160

tc(TB)

TBiIN input cycle time (counted on both edges)

300

Standard

Max.

Min.

Parameter

Symbol

Unit

tc(TB)

TBiIN input cycle time

600

tw(TBH)

TBiIN input HIGH pulse width

300

tw(TBL)

TBiIN input LOW pulse width

300

Standard

Max.

Min.

Parameter

Symbol

Unit

tc(TB)

TBiIN input cycle time

600

tw(TBH)

TBiIN input HIGH pulse width

300

tw(TBL)

TBiIN input LOW pulse width

300

Standard

Max.

Min.

Parameter

Symbol

Unit

tc(AD)

ADTRG input cycle time (trigger able minimum)

1500

tw(ADL)

ADTRG input LOW pulse width

200

Standard

Max.

Min.

Parameter

Symbol

Unit

tw(INH)

INTi input HIGH pulse width

380

tw(INL)

INTi input LOW pulse width

380

Standard

Max.

Min.

Parameter

Symbol

Unit

tc(CK)

CLKi input cycle time

300

tw(CKH)

CLKi input HIGH pulse width

150

tw(CKL)

CLKi input LOW pulse width

150

th(C-Q)

TxDi hold time

tsu(D-C)

RxDi input setup time

th(C-D)

RxDi input hold time

td(C-Q)

TxDi output delay time

160

Table 1.23.31. Timer B input (counter input in event counter mode)

Table 1.23.32. Timer B input (pulse period measurement mode)

Table 1.23.33. Timer B input (pulse width measurement mode)

Table 1.23.34. A-D trigger input

Table 1.23.35. Serial I/O

_______

Table 1.23.36. External interrupt INTi inputs
